Product details
W-GD81V-6L2 V.0
Price:¥面议
Contact and cooperate
Telephone:+86-755-82544054 83213461
Mailbox:sale@ipcwtm.com
- Specification
- Introduction
- Packing list
- Customer service
| The main chip | |
|---|---|
| Chip manufacturer | Intel |
| CPU chip position | Front |
| The cooling mode | Have a fan |
| CPU slot | LGA 1150(Haswell) |
| South chip | intel H81 |
| specification | |
| Memory type | DDR3 SODIMM |
| RAM | 2*DDR3 SODIMM |
| Storage | MSATA,SATA |
| Storage Detail | 1*SATA,1*MSATA |
| Expandable Slot | 1*PCIE 16X |
| The graphics sound network | |
| Network chip | RTL8111 |
| Net amount | 2 |
| The rear interface | |
| PW_SW | 1 |
Service commitment
1, From your purchase, the WTM to sell the product provide corresponding warranty period;
2, the WTM products implemented in different places to buy, the national Lianbao, namely no matter in any place you buy the WTM products, you choose any a WTM authorized service stations have a responsibility according to "WTM and service commitment" to you to provide services to ensure your satisfaction of using WTM products;
3, you can through call the nearby city of micro step authorized service station service hotline, consult the relevant technical problems. WTM provides you with six days a week, 9:00am-18:00pm phone hotline Advisory Service (except legal holidays). Hotline: +86-755-82544054
Supports 4th Gen Core, Pentium, Celeron (LGA1150), H81
- 2*DDR3 SODIMM, 1066/1333/1600 MT/s, Max 16GB
- 1*VGA+1*LVDS+1*HDMI, multiple display modes
- 2*USB3.0+13*USB2.0, 6*COM(COM1/2 supports RS485)
- 1*MSATA, 1*SATAⅢ, 1*4G/WIFI, 1*PCIEX16 (choose one)
- 2*RTL8111H LAN, 16-way GPIO, 1*LPT, DC24V power supply
